Specifications
1/4' Super HAD CCD
Active Pixels: 752H x 582V
Synchronization: Internal
Video Output: VBS 1.0Vp-p /75 ohms
White Balance: Auto/Manual
Scanning Frequency: 15625Khz (H) x 50Hz (V)
Resolution: More than 480 Lines
S/N Ratio: More than 46dB
Electronic Shutter: 1/50~1/30000s
Lux: 0.1 Lux
Lens Focal Length: f=3.9~63mm
Zoom: 216X (18X Optical 12X Digital)
Tilt Speed: 0~40 Degrees/s
Pan Rotation: 360 Degrees
Tilt Rotation: 90 Degrees (180 Degrees Auto Overturn)
Preset: 64
Control Way: Multiprotocol , RS485
Relative Humidity: 10-75%
Work Temperature: -45C~55C
Power Source: DC15VA 10%, 1.5A , External
Power Consumption: 15VA
Weight: 2Kg
