Main Processor
High performance Dual-core embedded microprocessor
Operating System
Embedded LINUX
System Resources
Pentaplex function: live, recording, playback, backup & remote access
Control Mode
Front panel, USB mouse, IR remote control, Keyboard, Network
Video
Input
16 channel, BNC(1.0Vp-p, 75 Ohms)
Standard
NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Output
1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC(1.0Vp-p, 75 Ohms)
Loop Output
16 channel
Audio
16 channel, BNC(200-2800mV, 30K Ohms)
1 channel, BNC(200-3000mV, 5K Ohms)
Bidirectional Talk
1 channel Input, BNC(200-2800mV, 30KΩ), 1 channel Output, BNC(200-3000mV, 5KΩ)
Display
Display Split
1/4/8/9/16
Spot Split
Resolution
1920x1080, 1280x1024, 1280x720, 1024x768
Tour Display
Support
Privacy Masking
4 self-defined four-sided zones for privacy masking for each camera
OSD
Camera title, time, video loss, camera lock, motion detection, recording
Recording
Video/Audio Compression
H.264 / G.711
Image Resolution
D1/4CIF(704×576/704×480) / HD1(352×576/352×480) / 2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120)
Encoding Speed
Main Stream: D1/HD1/2CIF/CIF(1~25/30fps)
Extra Stream: CIF/QCIF(1~25/30fps)
Bit Rate
32~4096Kb/s
Recording Quality
CBR, VBR(1~6 level, level 6 is the best)
Recording Mode
Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop
Recording Priority
Manual >Alarm >MD >Regular
Recording Interval
1~120 min. (default: 60 min.), Pre-record: 1~30 sec., Post-record: 10~300 sec.
Video Detection & Alarm
Trigger Events
Recording, PTZ movement, Tour, Alarm, Email, FTP, Spot, Buzzer & Screen tips
Motion Detection
Zones: 396(22×18), Sensitivity: 1~6 (level 6 is highest)
Video Loss & Camera Blank
Alarm Input
Relay Output
6 channel
Playback & Backup
Playback Channel
1/2/4/All
Search Mode
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Functions
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom(any size)
Backup Mode
Flash drive/ USB HDD/ USB CD&DVD-RW / eSATA Device / Built-in SATA burner/ Network download
Network
Ethernet
RJ-45 port (10/100M/1000M)
Network Functions
HTTP, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server
Remote Operation
Monitor, PTZ control, Playback, System setting, File download, Log information
Hard Disk
8 SATA ports, 8 HDDs or 6 HDDs + 1 CD/DVD-RW, Up to 24TB
eSATA
4 External SATA ports, up to 12TB
Space Occupation
Audio: 28.8MB/H, Video: 56~1800MB/H
HDD Management
HDD Group, HDD hibernation technology, HDD faulty alarm & Raid(Redundancy)
Auxiliary Interface
USB Interface
3 ports, For mouse control & backup
RS232
Dahua keyboard, PC communication
RS485
PTZ control
Environmental
Power Supply
AC 100~240 V, 50/60 Hz
Power Consumption
40W
Working Environment
-10 ~+55°C / 10~90%RH / 86~106kpa
Dimension
2U, 440mm×460mm×89mm(W×D×H)
Weight
14.5LB(without HDD)
