Parameter |
SCW 100X
|
|
Image Sensor |
1/4" Sony Super HAD CCD |
|
Total Image Pixels |
NTSC 811(H) x 508(V) 410K
PAL 795(H) x 596(V) 470K
Note: PAL only available as special order.
|
|
Number of Effective Pixel |
NTSC 768(H) x 494(V) 380K
PAL 752(H) x 582(V) 440K
|
|
Horizaontal resolution |
More than 530 TV lines |
|
Lens |
10X Optical Zoom (F1.8, f=3.9~38.0mm)
10x Digital Zoom (100x with optical)
|
|
Day & Night (ICR) |
Auto Day/Night |
|
Min. Focus Distance |
1.5m (5 feet) |
|
Digital Slow Shutter |
Auto /Off (2X ~ 128X) |
|
Min. Illumination |
Color: 0.7Lux @ F1.8, 0.005Lux (Digital Slow Shutter on) |
|
Min. Illumination |
Black/White: 0.02Lux @ F1.8 |
|
Luminance S/N Ratio |
More than 50dB |
|
Video Output |
CVBS: 1.0Vp-p/75Ohm (VBS EXT) |
|
Back Light Compensation |
ON / OFF |
|
Flickerless |
NTSC: ON/OFF (1/100)
PAL: ON/OFF (1/120)
|
|
White Balance |
AWB/ATW/Indoor/Outdoor |
|
Pan Rotation |
360 Degrees endless |
|
Pan Speed |
Manual: 100 Degrees ~ 150 Degrees/sec
Preset: Max 200 Degrees/sec
|
|
Tilt Rotation |
0 ~ 90 Degrees |
|
Tilt Speed |
Manual: 100 Degrees ~ 150 Degrees/sec (64 step)
Preset: Max 200 Degrees/sec
|
|
Accuracy |
0.02 Degrees |
|
# of Presets |
165 positions with different speed steps |
|
Group Tour |
Max. 8 programmable group tours |
|
Auto Scan |
Programmable Auto Scan |
|
Pattern |
8 Programmable paterns |
|
Privacy Zone |
4 Privacy Zones |
|
Sector |
8 Selectable Sectors |
|
Password Protection |
Yes |
|
Alarm Input |
4 Alarms Inputs (Off/NC/NO) |
|
Alarm Actions |
Activate preset, Group scanning, or Output |
|
Aux Output |
2 Replay Output |
|
Auto Flip |
ON/OFF |
|
OSD Menu |
Multiple language On-Screen-Display menu |
|
Communication |
RS-485 |
|
Protocol |
Pelco D/Pelco P |
|
Power Supply |
DC 12V 750mA |
|
Power Consumption |
9W Max. |
|
Construction |
Die-casting, Anti-vandal dome cover |
|
Dimensions |
158.8mm (D) x 163mm (H) |
|
Weight |
1.5kg (3.3lb) |
|
Motor Type |
Step Motor |
|
Micro Steps |
1/4 Micro Step |
|
Operating Temp. |
0C ~ 50C (32F ~ 122F) |
|
Operating Humidity |
30% ~ 80% RH |
|
Environmental Friendly |
ROHS certified (Lead-Free manufacturing process) |
